Home Theatre

There is nothing more frustrating than finally putting all the pieces of your home theater together, turning it on to watch your favorite movie and… all of a sudden, you are confronted with a terrible hum. In home audio systems, this is typically caused by the cable TV connection, less than ideal electrical wiring or voltage differentials known as DC offsets that often occur between two pieces of equipment. You can spend hours hopelessly trouble-shooting or simply insert an Iso-Max ground hum eliminator into the signal path to solve the problem. With a Jensen transformer inside, you can be sure that the signal quality will be maintained without distortion, phase shift or artefact of any kind.

PI-XX
Order #: J202-0100
More Info Buy Now $149.99

Line Input - Single channel isolator for professional line level inputs up to +19 dBu. May be used with any combination of balanced or unbalanced signals. Comes standard with XLR-F input and XLR-M output.

  • Primary application:
  • Frequency response:
  • Max signal handling:
  • CMRR noise rejection:
  • Standard connectors:
  • Optimal cable length:
  • Ground isolation for balanced line inputs
  • < 5 Hz to 40 kHz
  • +19 dBu @ 20 Hz, +22 dBu @ 50 Hz
  • 95 dB @ 60 Hz
  • XLR
  • Output - 1 m (3')
Buy Now
PI-2XX
Order #: J204-0200
More Info Buy Now $269.99

Line Input - Two channel isolator for professional line inputs up to +19 dBu. May be used with any combination of balanced or unbalanced signals. Comes standard with XLR-F inputs and XLR-M outputs.

  • Primary application:
  • Frequency response:
  • Max signal handling:
  • CMRR noise rejection:
  • Standard connectors:
  • Optimal cable length:
  • Ground isolation for balanced line inputs
  • < 5 Hz to 40 kHz
  • +19 dBu @ 20 Hz, +22 dBu @ 50 Hz
  • 95 dB @ 60 Hz
  • XLR with plug in screw terminal
  • Output - 1 m (3')
Buy Now
VB-1RR
Order #: J500-0122

Composite Video - Single channel 75 Ω transformer video isolator eliminates ‘hum bars’ caused by ground loops. Flanged enclosure for easy mounting with BNC or RCA input and output connectors.

  • Primary application:
  • Bandwidth:
  • Insertion loss:
  • CMRR noise rejection:
  • Standard Connectors:
  • CCTV camera isolation
  • 10 Hz to 10 Mhz
  • 0.55 dB
  • 120 dB @ 60 Hz
  • BNC or RCA
Buy Now
CI-1RR
Order #: J100-0111
More Info Buy Now $129.99

Line Input - Single channel isolator connects at the input of consumer level devices such as hi-fi & AV systems, laptops and automotive audio systems to remove noise via RCA connectors.

  • Primary application:
  • Frequency response:
  • Max signal handling:
  • CMRR noise rejection:
  • Standard connectors:
  • Optimal cable length:
  • Ground isolation for unbalanced RCA connections
  • < 10 Hz to 40 kHz
  • +19 dBu @ 20 Hz
  • 95 dB @ 60 Hz
  • RCA
  • Output - 1 m (3')
Buy Now
SUB-2XX
Order #: J208-0200
More Info Buy Now $299.99

Sub Woofer - Dual input isolator with extended low frequency response delivers full bass signal without compromise. Up to +24 dB signal handling at 20 Hz. Comes standard with XLR-F inputs and XLR-M outputs.

  • Primary application:
  • Frequency response:
  • Max signal handling:
  • CMRR noise rejection:
  • Standard connectors:
  • Optimal cable length:
  • Ground isolation for line inputs
  • < 1 Hz to 5 kHz
  • +19 dBu @ 20 Hz, +22 dBu @ 50 Hz
  • 105 dB @ 60 Hz
  • XLR with plug in screw terminal
  • Output - 1 m (3')
Buy Now
CI-RJ2R
Order #: J304-0277
More Info Buy Now $209.99

Audio to CAT-5 Converter - wo channel isolator sends -10 dB consumer level audio over CAT-5/6 cable for easy integration with network wiring. Passive design features send and receive modules for each end. Dual RCA input and output jacks with RJ45 connectors for CAT-5 termination.

  • Primary application:
  • Frequency response:
  • Max signal handling:
  • CMRR noise rejection:
  • Standard connectors:
  • Optimal cable length:
  • Extending Hi-Z signals using CAT-5 cable
  • < 5 Hz to 40 kHz
  • +19 dBu @ 20 Hz
  • 95 dB @ 60 Hz
  • RCA input & output, RJ45 extender
  • Output - 110 meters (350’)
Buy Now
CI-2RR
Order #: J100-0211
More Info Buy Now $199.99

Line Input - Two channel isolator connects at the input of consumer level devices such as hi-fi & AV systems, computer sound cards and automotive audio systems to remove noise via RCA connectors.

  • Primary application:
  • Frequency response:
  • Max signal handling:
  • CMRR noise rejection:
  • Standard connectors:
  • Optimal cable length:
  • Ground isolation for unbalanced RCA connections
  • < 10 Hz to 40 kHz
  • +19 dBu @ 20 Hz
  • 95 dB @ 60 Hz
  • RCA
  • Output - 1 m (3')
Buy Now
SP-2SX
Order #: J304-0280
More Info Buy Now $229.99

Speaker to Line Converter - Two channel isolator converts speaker level signals to +4 dBu balanced line level for distributed audio systems. Adjustable output via DIP switch. Comes with Speakon inputs and XLR outputs.

  • Primary application:
  • Frequency response:
  • Max signal handling:
  • CMRR noise rejection:
  • Standard connectors:
  • Optimal cable length:
  • Converting speaker level signals to line level
  • < 5 Hz to 40 kHz
  • DIP switch for 25, 75, 250 or 750 Watts
  • 95 dB @ 20 Hz
  • Speakon and XLR, plug in screw terminal
  • Output - 1 m (3')
Buy Now
SUB-1RR
Order #: J208-0111
More Info Buy Now $129.99

Low Frequency Line Input - Single channel device provides isolation at the input of a sub-woofer via RCA connectors. Extended low frequency response delivers bass down to 20 Hz without loss or distortion.

  • Primary application
  • Frequency response:
  • Max signal handling:
  • CMRR noise rejection:
  • Standard connectors:
  • Optimal cable length:
  • Ground isolation for consumer sub-woofers
  • < 1 Hz to 5 kHz
  • +20 dBu @ 20 Hz
  • 105 dB @ 60 Hz
  • RCA
  • Output - 1 m (3')
Buy Now
SUB-2RR
Order #: J208-0211
More Info Buy Now $199.99

Low Frequency Line Input - Two channel device provides isolation at the input of a sub-woofer via RCA connectors. Extended low frequency response delivers bass down to 20 Hz without loss or distortion.

  • Primary application:
  • Frequency response:
  • Max signal handling:
  • CMRR noise rejection:
  • Standard connectors:
  • Optimal cable length:
  • Ground isolation for consumer sub-woofers
  • < 1 Hz to 5 kHz
  • +20 dBu @ 20 Hz
  • 105 dB @ 60 Hz
  • RCA
  • Output - 1 m (3')
Buy Now
