Pro Audio

Jensen Iso-Max pro-isolators present a complete range of passive, hum-eliminating solutions for balanced and unbalanced signals where absolute audio performance is required. These feature ultra-wide frequency response, exceptional signal handling (up to +24dB) and immunity to external electromagnetic fields.  Built into an easy-to-install flanged outer shell, each model comes equipped with standard connectors or may be special ordered to suit. Also included is a terminal strip for greater connectivity plus a set & forget bottom-mount dip switch to optimize each setup to suit your specific installation. This makes the Jensen Iso-Max professional ground isolators well suited for broadcast, recording, live touring and the most demanding audio installations.

Product Filter

VIEW ALL

Mic Splitter - Eight channel 2-way passive mic splitter with one isolated and one direct output per channel. Features dual Faraday shields and MuMETAL® can to eliminate RF. Configurable phantom circuitry. Nema box ready for easy installation.

  • Primary application:
  • Frequency response:
  • Max signal handling:
  • CMRR noise rejection:
  • Standard connectors:
  • Eliminating noise on a mic input
  • < 10 Hz to 100 kHz
  • +2 dBu @ 20 Hz
  • 120 dB @ 60 Hz
  • Plug in screw terminal

Mic Splitter - Eight channel 3-way passive mic splitter with two isolated and one direct output per channel. Features dual Faraday shields and MuMETAL® can to eliminate RF. Configurable phantom circuitry. Nema box ready for easy installation.

  • Primary application:
  • Frequency response:
  • Max signal handling:
  • CMRR noise rejection:
  • Standard connectors:
  • Eliminating noise on a mic input
  • < 10 Hz to 100 kHz
  • +2 dBu @ 20 Hz
  • 120 dB @ 60 Hz
  • Plug in screw down terminal

Wall-mount Direct Box - Two channel passive multi-media DI converts unbalanced -10 dB consumer level signals to balanced. Variable level control, mono-sum and ground lift. Fits single gang electrical box with Decora® plate.

  • Primary application:
  • Frequency response:
  • Max signal handling:
  • Standard connectors:
  • Converting unbalanced consumer signals to pro
  • 20 Hz to 20 kHz
  • +17 dBu
  • RCA and 3.5 mm inputs with plug in screw terminal

Mic Splitter & Isolator - Two channel device provides ground isolation and RFI suppression for low impedance 150~200 Ω balanced microphone signals. Configurable for stereo two way mic ‘splitter’ or noise eliminator.

  • Primary application:
  • Frequency response:
  • Max signal handling:
  • CMRR noise rejection:
  • Standard connectors:
  • Optimal cable length:
  • Eliminating noise on a mic input
  • < 10 Hz to 100 kHz
  • +2 dBu @ 20 Hz
  • 120 dB @ 60 Hz
  • XLR with plug in screw terminal
  • Output - 30 m (100')

Audio to CAT-5 Converter - Two channel isolator sends -10 dB consumer level audio over CAT-5/6 cable for easy integration with network wiring. Passive design features send and receive modules for each end. Dual RCA input and output jacks with RJ45 connectors for CAT-5 termination.

  • Primary application:
  • Frequency response:
  • Max signal handling:
  • CMRR noise rejection:
  • Standard connectors:
  • Optimal cable length:
  • Extending Hi-Z signals using CAT-5 cable
  • < 5 Hz to 40 kHz
  • +19 dBu @ 20 Hz
  • 95 dB @ 60 Hz
  • RCA input & output, RJ45 extender
  • Output - 110 meters (350’)

Pro to Consumer - Two channel isolator converts +4 dB professional balanced signals down to -10 dB for use with consumer audio devices such as laptops or video recorders. Comes with XLR-F inputs and RCA outputs.

  • Primary application:
  • Frequency response:
  • Max signal handling:
  • CMRR noise rejection:
  • Standard connectors:
  • Optimal cable length:
  • Converting +4 dB balanced to -10 dB unbalanced
  • < 10 Hz to 140 kHz
  • +21 dBu @ 20 Hz, +24 dBu @ 50 Hz
  • 120 dB @ 60 Hz
  • XLR and RCA with plug in screw terminal
  • Output - 1 m (3')

Speaker to Line Converter - Two channel isolator converts speaker level signals to +4 dBu balanced line level for distributed audio systems. Adjustable output via DIP switch. Comes with Speakon inputs and XLR outputs.

  • Primary application:
  • Frequency response:
  • Max signal handling:
  • CMRR noise rejection:
  • Standard connectors:
  • Optimal cable length:
  • Converting speaker level signals to line level
  • < 5 Hz to 40 kHz
  • DIP switch for 25, 75, 250 or 750 Watts
  • 95 dB @ 20 Hz
  • Speakon and XLR, plug in screw terminal
  • Output - 1 m (3')
